| tem | V1600G1-B |
| Chassis | Rack | 1U 19 inch standard box |
| | QTY | 8 |
| | Copper 10/100/1000M auto-negotiation | 4 |
| 1G/10G | SFP 1GE | 2 |
| Uplink Port | SFP+ 10GE | 2 |
| | QTY | 8 |
| GPON Port | Physical Interface | SFP Slot |
| | Connector Type | Class C+ |
| | Max splitting ratio | 0,130555556 |
| Management Ports | 1*10/100BASE-T out-band port, 1*CONSOLE port |
| | Transmission Distance | 20KM |
| | GPON port speed | Upstream 1.244G |
| | Downstream 2.488G |
| PON Port Specification(Class C+ module) | Wavelength | TX 1490nm, RX 1310nm |
| | Connector | SC/UPC |
| | Fiber Type | 9/125μm SMF |
| | TX Power | +3～+7dBm |
| | Rx Sensitivity | -30dBm |
| | Saturation Optical Power | -12dBm |
| Dimension(L*W*H) | 442*220*43.6mm |
| Weight | 3.1kg |
| AC Power Supply | AC:100～240V, 47/63Hz |
| DC Power Supply(DC:-48V) | √ |
| Double Power Module Hot Backup | √ |
| Power Consumption | 45W |
| | Working Temperature | 0～+50℃ |
| O p e r a t i n g Environment | Storage Temperature | -40～+85℃ |
| | Relative Humidity | 5～90%(non-conditioning) |
